ICCP Polymer anode MMO Anodes ( Mixed Metal Oxide) for Cathodic protection
Product Details:
Place of Origin: | China |
Brand Name: | High Broad or OEM |
Certification: | ISO, DNV,BV |
Model Number: | ASTM B348 GRADE I/II |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 meter |
---|---|
Price: | negotiable |
Packaging Details: | on pallet |
Delivery Time: | 1FCL: 14 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal |
Supply Ability: | 30000meters/month |
Detail Information |
|||
Application: | LMMO/Ti Linear Anode For Buried Pipelines | Standard: | Continuous MMO Ti Wire Coated Flexible Linear Anodes For Underground Pipeline Cathodic Protection |
---|---|---|---|
Shape: | Mixed Metal Oxide Titanium Flexible Anode | Content: | Impressed Current Cathodic Protection |
Type: | Impressed Current C Anode ICCP | ||
High Light: | sacrificial zinc anodes,alloy sacrificial anode |
Product Description
ICCP Polymer anode,MMO Anodes ( Mixed Metal Oxide) for Cathodic protection
Item | Parameters |
Model P/N |
MMO/Ti Wire Anode 1.5mm Dia) ELTA-30(MMO/Ti Wire Anode 3mm Dia) |
Outer Dia. | 38-40mm |
MMO/Ti wire anode Dia. | 1.5mm,3mm |
Current output | =52mA/m, customizable |
Designed life | =40Y, customizable |
Cable | 1×10mm2/ Halar,HMWPE/PVC or HMWPE are optional. |
Carbon breeze content | =98.5% |
Carbon breeze resistivity | ~0.05O·cm,per G.L.C.-C-12A at 23ºC, 10 bar |
MMO wire and cable contact resistance | =0.0009O |
Anode weight | 1.3-1.5Kg/m |
Length per roll | 500m;1000m |
Bursting strength | 575 N per ISO 3303 |
Abrasion resistance | 219 cycles to failure per ASTM D-4157 |
Fluid resistance | Pass, 6-month immersion test |
Chlorine resistance | Pass, 6-month immersion test |
UV resistance | 55% tear strength loss per ASTM G-53, 8 hrs @ 60ºC (140ºF), 4 hrs condensation @ 50ºC (122ºF) |
Package: in roll
