ASTM Magnesium Alloy Extruded Rods Sacrificial Anodes
Product Details:
| Place of Origin: | China |
| Brand Name: | High Broad |
| Certification: | ISO |
| Model Number: | High Broad |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100kgs |
|---|---|
| Price: | TBA |
| Packaging Details: | Plywooden case for export |
| Delivery Time: | 1 FCL: 14 Days |
| Payment Terms: | T/T |
| Supply Ability: | 5000MT per year |
|
Detail Information |
|||
| Material: | Magnesium Anode | Size: | According To Customer's Requirement |
|---|---|---|---|
| Usage: | Water Heater Boiler And Tank | Screw Type: | NPT/ BSP/ BSW / NPE-ASMT |
| Keywords: | 3/4NPT Screw Magnesium Anode Rod For Water Heater Cathodic Protection | Technology: | Cast Or Extruded |
| Name: | Magnesium Rod Anode | Standard: | ASTM |
| High Light: | Magnesium Alloy Extruded Rods,Magnesium Alloy Sacrificial Anodes,ASTM Sacrificial Anodes |
||
Product Description
ASTM Magnesium Alloy Extruded Rods Sacrificial Anodes
Specifications
Magnesium alloy extruded rods Anodes are excellent sacrificial rods, used to protect the inside metal surface of your water heater tank. The magnesium corrodes instead of your tank. The standard anodes can be used for all tank sizes and types (all brands) , are available optionally with a M4,M6,M8 bolt,etc. with a screw connection or adapter G ¾“, G1“, G 1 ¼“, G 1 ½“,etc.
| Anode Dia(mm) | length(mm) | Insert |
| Φ13 | 115 | M4 |
| Φ14 | 150 | M6 |
| Φ14 | 180 | M6 |
| Φ14 | 215 | M6 |
| Φ14 | 275 | M6 |
| Φ16 | 90 | M4 |
| Φ16 | 100 | M6 |
| Φ16 | 155 | M6 |
| Φ24 | 300 | M8 |
| Φ25.4 | 500 | M8 |
Application
Magnesium alloy extruded rods Anodes are mainly used in water heater, boiler, heat exchanger, water tank,etc.It has properties of softing water, de-dirt residual ,en-longing the working life of container.
Chemical compositions
| Type | Al | Zn | Mn | Fe | Cu | Ni | Si | Others | Mg |
| AZ31B | 2.5-3.5 | 0.6-1.4 | 0.2-1.0 | 0.005 | 0.01 | 0.001 | 0.1 | 0.3 | Balance |
| Mg-Mn | 0.01 | - | 0.5-1.3 | 0.03 | 0.02 | 0.001 | 0.05 | 0.3 | Balance |
Electrochemical properties
| Type | Open-circuit voltage (-V) | Close-circuit voltage (-V)Zn | Actual capacitance (A·h/g) | Current efficiency (%) |
| AZ31B | 1.50-1.55 | 1.45-1.50 | ≥1.105 | ≥50 |
| Mg-Mn | 1.70-1.75 | 1.57-1.62 | ≥1.100 | ≥50 |
We can do according to customized size and requirements.
