Silicon Carbide Bulletproof Plates with NIJ Level IV Protection 3.15g/cm3 Density and HV2750 Hardness for Armored Vehicles
Product Details:
| Place of Origin: | China |
| Brand Name: | OEM/High Broad |
| Certification: | ISO |
| Model Number: | NIJ III IV silicon carbide & UHMWPE insert bulletproof vest plate |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 kilograms |
|---|---|
| Price: | negotiable |
| Packaging Details: | Each nozzle packed in a plastic tube, then in a carton |
| Delivery Time: | 10 tons:14Days |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,,PayPal |
| Supply Ability: | 100 MT per month |
|
Detail Information |
|||
| Density: | 3.15g/cm3 | Shape: | Square, Hexongal, Rectangular, Round |
|---|---|---|---|
| Grade: | NIJ III, NIJ IV | Hardness: | HV2750 |
| Flexural Strength: | 380 Mpa | Compressive Strength: | 3970 Mpa |
| Highlight: | silicon carbide tiles,bulletproof ceramic plates |
||
Product Description
Silicon Carbide Bulletproof Plates for Heavy Armored Protection
Silicon Carbide (SiC) bulletproof plates and tiles designed for heavy armored protection applications including armored vehicles, aircraft, tanks, and ships.
Primary Applications
Widely used in heavy armored protection systems for aircraft, tanks, naval vessels, and high-level personal protection equipment.
Material Properties Comparison
| Property | Al₂O₃ | SiC | B₄C |
|---|---|---|---|
| Density | 3.5 g/cm³ | 3.1 g/cm³ | 2.4-2.65 g/cm³ |
| Hardness | HV1650 | HV2750 | HV3300 |
| Flexural Strength | 290 MPa | 380 MPa | 400-650 MPa |
| Compressive Strength | 850 MPa | 3970 MPa | 4100 MPa |
| Fracture Toughness | 4.8 MPa·m¹/² | 4.0 MPa·m¹/² | 4.5-7.0 MPa·m¹/² |
| Thermal Conductivity | 20 m/K | 120 m/K | 29 m/K |
| Coefficient of Thermal Expansion | 7.2×10⁻⁶ | 4×10⁻⁶ | 4.5×10⁻⁶ |
With the increasing frequency of active shooter incidents worldwide, there is growing demand from law enforcement and personnel for advanced armor plate protection solutions, extending beyond urban environments to various operational theaters.
