Aluminum Jacket Sandblasting Nozzles With High Hardness And Wear Resistance

China Aluminum Jacket Sandblasting Nozzles With High Hardness And Wear Resistance supplier
Aluminum Jacket Sandblasting Nozzles With High Hardness And Wear Resistance supplier Aluminum Jacket Sandblasting Nozzles With High Hardness And Wear Resistance supplier

Large Image :  Aluminum Jacket Sandblasting Nozzles With High Hardness And Wear Resistance

Product Details:

Place of Origin: CHINA
Brand Name: HIGH BROAD
Certification: ISO
Model Number: Boron carbide Straight Bore nozzle

Payment & Shipping Terms:

Packaging Details: Nozzle in plastic tube then in export carton
Contact Now
Detailed Product Description
Material: Boron Carbide Straight Bore Nozzle With Aluminum Jacket Thread: 2",4-1/4 U.N.C.
Type: Boron Carbide Liner With Aluminum Jacket And Threads Or Flange Advantage: High Hardness And Wear Resistance

The boron carbide nozzle has an aluminum jacket and 2″ Contractor threads. It is a long venturi nozzle suitable for a wide range of abrasive blasting applications like open open blasting or blast rooms and is designed for cost effectiveness. Each nozzle comes with a washer for quick assembly.



Features:

  • Lightweight, durable aluminum jacket
  • long venturi provides supersonic abrasive velocity
  • #4 nozzle, 10-101, features a 1″ throat entry
  • All other sizes are 1-1/4″ throat entry
  • All are 50mm 2″ contractor style coarse thread.

Nozzle Couplings for the 2″ contractor thread nozzles

Aluminum Jacket Sandblasting Nozzles With High Hardness And Wear Resistance

Straight hole nozzle has the characteristics of a simple structure, only with the converging section and straight section. However, this kind of nozzle also has the problem of the vortex

at the entry area, high pressure loss and low outlet velocity, as lower as 50% of Venturi nozzle.



Boron carbide liner with aluminum jacket and threads or flange

Thread Style: 2",4-1/4 U.N.C.
MODEL NO.
I.D.
O.D.
LENGTH
HB-SBS-4
1/4" (6.4mm)
1-5/8" (42mm)
130mm
HB-SBS-5
5/16"(7.9mm)
1-5/8" (42mm)
150mm
HB-SBS-6
3/8" (9.5mm)
1-5/8" (42mm)
170mm
HB-SBS-7
7/16"(11.1mm)
1-5/8" (42mm)
200mm
HB-SBS-8
1/2" (12.7mm)
1-5/8" (42mm)
210mm

long venturi  nozzle.pdf

Straight hole nozzle is usurally used withinthe sand-blasting machines,which have low spray

intensity and narrow closed struture.

Product Advantage:

(1)High hardness and wear resistance
(2)Heat resistance and corrosion resistance

(3)High quality, lowest price

(4)Long service live

nozzle.pdf
