MMO Linear Anode with Copper Core for 20 Years Design Life in Buried Pipeline Protection
Product Details:
| Place of Origin: | China |
| Brand Name: | High Broad or OEM |
| Certification: | ISO, DNV,BV |
| Model Number: | ASTM B348 GRADE I/II |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 meter |
|---|---|
| Price: | negotiable |
| Packaging Details: | on pallet |
| Delivery Time: | 1FCL: 14 days |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,,Paypal |
| Supply Ability: | 30000 meters/month |
|
Detail Information |
|||
| Type: | Grid Anodes MMO | Shape: | Mmo-surfaced Anodes ,Polymeric Anodes For Improved Polymer Light-emitting |
|---|---|---|---|
| Substrate Material: | Titanium To ASTM Grade 1 Or 2 | Design Life: | 20 Years At 100 A/m2 |
| Ti Wire Diameter: | 1.5 Mm Or 3 Mm | Current Output: | 0.5 A/m (1.5mm) Or 1A/m (3mm) |
| Highlight: | sacrificial anode protection,magnesium sacrificial anode |
||
Product Description
MMO Discrete Anodes Copper Core Linear Anode For Cathodic Protection System
Mixed Metal Oxide Activated Titanium Wire Anodes provide reliable cathodic protection with a nominal design life of 20 years when operating at optimal current density.
Product Specifications
- Activation: Noble Mixed Metal Oxides consisting of IrO₂ and Ta₂O₅
- Substrate Material: Titanium to ASTM Grade 1 or 2
- Working Environment: Evolution of O₂, Cl₂ or combination of both
- Nominal Design Life: Typically 20 years at 100 A/m² anode current density
- Coating Loading: Adjustable for any combination of current output and design life
Dimensions & Configurations
- Dimension of Ti Wire: 1.5 mm diameter or 3 mm diameter
- Current Output: 1.5 mm dia. - 0.5 A/m; 3.0 mm dia. - 1 A/m
- Lengths: From 1 m to 50 m (longer lengths available on request)
- Header Cable: Typically 10 mm² or 16 mm² XLPE/PVC
- Cable Connections: Every 10 m (adjustable for soil resistivity)
- Cable Tail: 1 m to 5 m at one or both ends
Applications
3mm Ø Wire Applications:
- New Construction Tank Bottom CP
- Replacement Tank Bottom CP
1.5mm Ø Wire Applications:
- Parallel Anode Pipeline CP
- Underground Cable Ducts CP
Key Advantages
Easy to Install - Cost Effective
Arrives on Site Ready to Lay in Place
Follows Structure Symmetry for Maximum Efficiency
100% Factory Connections - High Quality Control
Continuous Anode Technology
Optimized Current Distribution
Optimized Power Efficiency
Optimized Low Groundbed Resistance
