Extruded/Casting Corrosion Resistant Lightweight Magnesium Alloy Plate and Sheet for Aerospace Applications
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | HB |
| Certification: | ISO9001,ISO14001,EJ/T9001-2005 |
| Model Number: | AZ31 AZ61 AZ91 WE43 ZK60 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 |
|---|
|
Detail Information |
|||
| Chemical Composition: | AI:2.5-3.5%;Zn:0.7-1.3%;Mn:0.20-1.0%;Mg:Balance | Material: | Magnesium Alloy |
|---|---|---|---|
| Shape: | Sheet/plate/board | Process: | Extruded/Casting |
| Thickness Range: | 0.5 To 7mm | Max Width: | 600mm |
| Max Length: | 1200mm | Melting Point: | 650 °C |
| Boiling Point: | 1090 °C | Density: | 1738 Kg/m3 |
| Electrical Resistivity: | 4.45 Microhm-cm @ 20 °C | Thermal Conductivity: | 1.56 W/cm/K @ 298.2 K |
| Thermal Expansion: | 24.8 µm*m-1*K-1 @ 25 °C | Young's Modulus: | 45 GPa |
| Poisson's Ratio: | 0.29 | ||
| Highlight: | Extruded/Casting Magnesium Alloy Plate,Corrosion Resistant Magnesium Sheet,Lightweight Magnesium Alloy Plate |
||
Product Description
Mg Plate Sheet Slab Cast and Roll Magnesium Alloy AZ31B H24 Az31 Az91 We43 We54 We94 Zk60 AM60
Product Description
High purity magnesium alloy plates in various grades including AZ31B, AZ91, WE43 and more.
Deviations from flat are measured from a straight edge placed on the surface of the plate.
Finish: The side suitable for tooling uses is stencilled. The opposite side is equal or superior to a mill finish.
Packing: Conforms to requirements of carrier through which shipment is made. Both domestic and export packing available.
Magnesium Alloy and Form
- AZ31 / AZ31B - Rod, Tooling Plate
- AZ31B-H24 - Spec Grade - Sheet & Plate Sheet, Plate
- AZ91C - As cast or heat treated - Castings
- AZ91E - As cast or heat treated - Castings
- AZ80 - Bar
- EV31A - As cast or heat treated - Castings
- ZE41A - As cast or heat treated - Castings
- ZK60A - Bar, Sheet, Plate
Product Specifications
| Application | CNC engraving |
|---|---|
| Shape | sheet/plate/board |
| Chemical Composition | AI:2.5-3.5%;Zn:0.7-1.3%;Mn:0.20-1.0%;Mg:Balance |
| Process | Extruded/Casting |
| Size | thickness from 0.5 to 7mm; Max width is 600mm; Max. length is 1200mm |
| Other name | Magnesium Alloy Rod Bar |
| Type | MIC,High potential,AZ63C,AZ31 |
| Certification | ISO9001,ISO14001,EJ/T9001-2005 |
| Packaging | In Carton /wood crate/on pallet |
Magnesium Sheet Properties (Theoretical)
| Molecular Weight | 24.31 |
|---|---|
| Appearance | Gray |
| Melting Point | 650 °C |
| Boiling Point | 1090 °C |
| Density | 1738 kg/m3 |
| Electrical Resistivity | 4.45 microhm-cm @ 20 °C |
| Heat of Fusion | 2.16 Cal/gm mole |
| Heat of Vaporization | 32.517 K-Cal/gm atom at 1090 °C |
| Poisson's Ratio | 0.29 |
| Specific Heat | 0.243 Cal/g/K @ 25 °C |
| Thermal Conductivity | 1.56 W/cm/K @ 298.2 K |
| Thermal Expansion | (25 °C) 24.8 µm*m-1*K-1 |
| Young's Modulus | 45 GPa |
Available Forms
| AZ31-TP Tooling Plate From .250″ to 14″ thickness | AZ31B-H24 Sheet & Plate From .020″ to 3″ thickness |
| AZ31B-O Sheet & Plate From .020″ to 3″ thickness | AZ31B-F Round Bar From .250″ to 14″ diameter |
| ZK60A-T5 Flat Bar Many sizes!! | ZK60A-F Flat Bar Many sizes!! |
| ZK60A-T5 Round Bar From 1″ to 15″ diameter | ZK60A-F Round Bar From 1″ to 15″ diameter |
| AZ61A-F Round Bar From 1″ to 3.125″ diameter | Forgings, Castings, and Special Extruded Shapes |
Other Available Grades
- WE43
- WE54
- WE94
- AZ91D
Our Advantages
EXPERIENCE
16 years producing and international marketing experience!
STOCK
Various sizes plate stock can make prompt shipment!
TEAM
State-owned enterprises professional work experience team!
QUALITY
Advanced technical engineers & Advanced lab test machines make high quality assured!
CREDIT
On time delivery & 100% contract fulfil rate!
Want to Know more details about this product
