Hotpress Boron Carbide Spray Nozzle
Product Details:
| Place of Origin: | China |
| Brand Name: | OEM |
| Model Number: | Hotpress Boron Carbide Spray Nozzle |
|
Detail Information |
|||
| Material: | Boron Carbide Spray Nozzle | Type: | Hotpress |
|---|---|---|---|
| Usage: | Used For Blasting Spray Gun | ||
| Highlight: | Hotpress boron carbide spray nozzle,Boron carbide nozzle with warranty,Spray nozzle for magnesium anode |
||
Product Description
Wear Resistance Aluminum Jacket Type Sandblasting Boron Carbide Nozzle Sandblasting Nozzle Carbide
Specification:
Density> =2.48g/cm3;
Hardness> =3500kgf/sqm, bending resistance: ≥ 400Mpa
Melting point: 2450degree
Woking conditions:High temperature, high pressure, grinding, acid and alkali
Material :Bore carbide ,Silicon, Tungsten carbide
The size can be customized as per drawing
Jacket type: Aluminum,MS,Nylon jackets,Stainless Steel
Approximate Nozzle Service Life in Hours :
|
Nozzle material |
Steel Shot and Grit |
Expendable Abrasives |
Aluoxide Abrasives |
|
Alumina |
20-40 |
10-30 |
1-4 |
|
Tungsten Carbide |
500 - 800 |
300 - 400 |
20-40 |
|
Silicon carbide |
600-1000 |
400-600 |
50-100 |
|
Boron Carbide |
1500 - 2500 |
750 - 1500 |
200 -1000 |
Boron carbide nozzle is the best material of the nozzle, high durability, is six times more. The company produced tungsten boron carbide raw material, high purity boron carbide nozzle and the product quality is good, low price, complete specifications, including 35MM, 45MM, 60MM, 80MM, 82MM five length specifications.
Parameter:
|
Part Number |
ID(mm) |
OD(mm) |
Length(mm) |
|
BC35 |
4,6,8,10 |
20 |
35 |
|
BC45 |
4,6,8,10 |
20 |
45 |
|
BC55 |
4,6,8,10 |
20 |
55 |
|
BC60 |
4,6,8,10 |
20 |
60 |
|
BC80 |
4,6,8,10 |
20 |
80 |
