Flexible Link Segmented Magnesium Water Heater Anode Rod 32 Inch for Low Clearance Tank Installation
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | WNRLN |
| Certification: | ISO 9001:2015 |
| Model Number: | WAR-FL32 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50 Pieces |
|---|---|
| Price: | USD 6.90-12.50 / Piece |
| Packaging Details: | Individual retail-ready poly bag with hang hole, instruction insert, export carton, 20 pieces per carton |
| Delivery Time: | 5 working days for stock, 15-25 days for production |
| Payment Terms: | T/T, L/C, PayPal, Western Union |
| Supply Ability: | 50000 Pieces per Month |
|
Detail Information |
|||
| Diameter: | 0.75 Inch (19mm) | Overall Length: | 32 Inch (813mm) |
|---|---|---|---|
| Thread Type: | 3/4 Inch NPT Male | Core Material: | Stainless Steel Wire |
| Anode Material: | AZ63 Magnesium Alloy | Segment Count: | 6 Articulated Links |
| Weight: | 1.40 Lbs (635g) | Min Ceiling Clearance: | 12 Inches |
| Highlight: | flexible link magnesium water heater anode rod,segmented water heater anode rod for low clearance,32 inch magnesium anode rod with warranty |
||
Product Description
Flexible Link Segmented Magnesium Anode Rod 32 Inch
The WNRLN WAR-FL32 solves the most frustrating challenge in water heater maintenance: replacing the anode rod when there is limited overhead clearance. Traditional straight anode rods require approximately the same vertical clearance as the rod length to install. This innovative flexible link design divides the 32 inch magnesium rod into 6 articulated segments connected by stainless steel wire, allowing the rod to bend as it is inserted into the tank opening.
Key Features
- Low Clearance Installation: Requires only 12 inches of overhead space vs. 32+ inches for rigid rods
- 6 Articulated Segments: Smooth bending radius conforms to insertion angle
- No Plumbing Disconnect: Install without removing vent pipes or disconnecting water lines
- Stainless Steel Core Wire: Flexible yet durable, prevents segment separation
- Full Sacrificial Protection: Complete magnesium coverage equivalent to a solid rod
- DIY Friendly: Includes illustrated installation instructions
Technical Specifications
| Anode Material | AZ63 Magnesium Alloy per segment |
| Connecting Core | 304 Stainless Steel Wire, Diameter 3.0mm |
| Thread Size | 3/4 inch NPT Male (solid brass adapter) |
| Rod Diameter | 19mm (0.75 inch) per segment |
| Overall Length | 813mm (32 inch) |
| Segment Length | 115mm per segment (6 segments) |
| Net Weight | 635g ± 15g |
