Industrial 1 Inch NPT Heavy Duty Magnesium Anode Rod 40 Inch for Large Commercial Boiler Tank Cathodic Protection
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | WNRLN |
| Certification: | ISO 9001:2015, CE, ASME BPE |
| Model Number: | WMR-ID40 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 20 Pieces |
|---|---|
| Price: | USD 8.90-18.50 / Piece |
| Packaging Details: | Heavy duty VCI poly tube with end plugs, industrial export crate, 10 pieces per crate |
| Delivery Time: | 5 working days for stock, 20-30 days for production |
| Payment Terms: | T/T, L/C, PayPal, Western Union |
| Supply Ability: | 20000 Pieces per Month |
|
Detail Information |
|||
| Diameter: | 1.0 Inch (25.4mm) | Overall Length: | 40 Inch (1016mm) |
|---|---|---|---|
| Thread Type: | 1 Inch NPT Male | Core Material: | Reinforced Galvanized Steel 6mm |
| Anode Material: | High Density Magnesium Alloy | Rod Weight: | 3.30 Lbs (1497g) |
| Tank Type: | Commercial Boiler / Industrial Storage | Tank Size Range: | 200-500 Gallons |
| Highlight: | 1 inch NPT magnesium anode rod,heavy duty magnesium anode rod for boiler,40 inch commercial boiler anode rod |
||
Product Description
Industrial 1" NPT Heavy Duty Magnesium Anode Rod 40" for Commercial Boilers
The WNRLN WMR-ID40 is engineered for the most demanding industrial cathodic protection applications. With an oversized 1 inch NPT thread, 25.4mm rod diameter, and 6mm reinforced steel core, this anode rod provides the durability and protection capacity required for commercial boilers, industrial hot water storage, and large process water heating systems handling 200-500 gallon tanks. CE certified and manufactured to ASME BPE standards.
Key Features
- 1 Inch NPT Thread: Heavy duty fitting for large commercial tank ports
- 25.4mm Rod Diameter: Double the sacrificial material of standard residential rods
- 6mm Steel Core: Reinforced core prevents mechanical failure during industrial service
- ASME BPE Compliant: Manufactured to bioprocessing equipment standards
- Industrial Packaging: Crates designed for industrial supply chain handling
Technical Specifications
| Anode Material | High Density Magnesium Alloy (Mg ≥ 90%) |
| Core Rod | Reinforced Galvanized Steel, Diameter 6.0mm |
| Thread Size | 1 inch NPT Male |
| Rod Diameter | 25.4mm (1.0 inch) |
| Overall Length | 1016mm (40 inch) |
| Net Weight | 1497g ± 35g |
| Certification | ISO 9001, CE, ASME BPE |
