Silicon Carbide Bulletproof Plate - NIJ Level IV Standalone with Multi-Hit Capability and Pressureless Sintered Technology
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | ECER |
| Certification: | NIJ 0101.06, ISO 9001:2015 |
| Model Number: | BP-SIC-L4-1012-S |
| Document: | SIC Ballistic Armor Tiles-P...ad.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 30kg |
|---|---|
| Price: | USD20-40.00/kg |
| Packaging Details: | ECER branded shock-proof foam packaging with export-grade corrugated carton |
| Delivery Time: | 5 working days for stock, 15-30 days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 500 mts per Month |
|
Detail Information |
|||
| Density: | 3.10-3.15 G/cm³ | Size: | 250 X 300 Mm (10x12 Inch) |
|---|---|---|---|
| Flexural Strength: | ≥380 MPa | Multi-Hit Capability: | ≥3 Rounds 7.62x51mm M80 NATO |
| Weight: | 2.5-3.2 Kg Per Plate | Thickness: | 12-18 Mm |
| Highlight: | Sintered SiC Ceramic Armor Plate,NIJ Level IV Multi-Hit Composite,Low Density High Hardness Bulletproof |
||
Product Description
Silicon Carbide Sintered Ceramic Bulletproof Plate - NIJ Level IV Stand alone
The Silicon Carbide (SiC) Sintered Ceramic Bulletproof Plate is a high-performance ballistic armor insert designed for NIJ Level IV standalone protection. Manufactured using advanced pressureless sintering technology, this ceramic plate delivers exceptional hardness, low density, and outstanding multi-hit resistance against high-power ammunition.
Key Features
- High Hardness: SiC ceramic with hardness exceeding 2600 HV (Knoop 2800), capable of fracturing armor-piercing projectiles upon impact.
- Low Density: At only 3.10-3.15 g/cm³, this plate is 20-30% lighter than traditional alumina ceramic armor, reducing wearer fatigue in extended tactical operations.
- Superior Multi-Hit Capability: Engineered to withstand at least 3 rounds of 7.62x51mm M80 NATO ball ammunition without catastrophic cracking, ensuring sustained protection in combat scenarios.
- High-Power Ammunition Rated: Independently verified to stop .30-06 M2 AP rounds at velocities up to 878 m/s, meeting NIJ 0101.06 Level IV standards.
- Pressureless Sintered: Uniform microstructure achieved through advanced pressureless sintering ensures consistent ballistic performance across the entire plate surface.
Technical Specifications
| Material | Silicon Carbide (SiC) Ceramic |
| Density | 3.10-3.15 g/cm³ |
| Hardness | ≥2600 HV / Knoop 2800 |
| Ballistic Standard | NIJ 0101.06 Level IV (Standalone) |
| Size | 250 x 300 mm (10x12 inch) |
| Thickness | 12-18 mm |
| Multi-Hit Capability | ≥3 rounds 7.62x51mm M80 NATO |
| Fracture Toughness | 3.5-4.0 MPa·m½ |
| Flexural Strength | ≥380 MPa |
| Sintering Method | Pressureless Sintered |
| Curvature Options | Single Curve / Multi Curve |
| Weight | 2.5-3.2 kg per plate |
Applications
Ideal for tactical tactical vests, law enforcement body armor, vehicle armor spall liners, and fixed-position ballistic shields. Compatible with standard SAPI/ESAPI plate carrier systems.
Why Choose Our SiC Bulletproof Plates?
Unlike conventional alumina ceramic plates that shatter on first impact, our pressureless sintered silicon carbide plates exhibit superior fracture toughness (3.5-4.0 MPa·m½), enabling multiple hit resistance without catastrophic failure. The low density (3.10-3.15 g/cm³) reduces the overall weight of body armor systems by up to 30% compared to alumina equivalents, significantly improving mobility and operational endurance. Each plate undergoes rigorous quality control including ultrasonic flaw detection and batch ballistic testing to ensure consistent protection.
