NIJ Level IV Monolithic Silicon Carbide Plate 10x12 Inch Ballistic Protection Ceramic Plate
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | High Broad |
| Certification: | NIJ 0101.06 Level IV, ISO 9001:2015 |
| Model Number: | HB-SIC-4M-1012 |
| Document: | SIC Ballistic Armor Tiles-P...ad.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 Pieces |
|---|---|
| Price: | USD 65-85 / Piece |
| Packaging Details: | Individual EPE foam wrapping with corrugated box, export-grade plywood pallet |
| Delivery Time: | 5-7 working days for samples, 15-25 days for bulk orders |
| Payment Terms: | T/T,L/C,Western Union,PayPal |
| Supply Ability: | 5000 Pieces per Month |
|
Detail Information |
|||
| NIJ Protection Level: | Level IV (.30-06 M2 AP) | Hardness: | 2600 HV (Knoop) |
|---|---|---|---|
| Weight: | 2.8 Kg (Single Plate) | Operating Temperature: | -40°C To +70°C |
| Density: | 3.15 G/cm³ | Areal Density: | 28.5 Kg/m² |
| Highlight: | Affordable NIJ IV SiC Plate,Boron Carbide Alternative Armor,Monolithic Ceramic Ballistic Armor |
||
Product Description
Silicon Carbide Monolithic Protection Plate NIJ IV 10x12 Inch SiC tile
Silicon Carbide NIJ Level IV Monolithic Plate — Boron Carbide Performance, Sensible Price
SiC vs Boron Carbide: The Smart Procurement Choice
| Property | Silicon Carbide (SiC) | Boron Carbide (B₄C) | Analysis |
|---|---|---|---|
| Hardness (Knoop) | 2,600 HV | 2,800-3,000 HV | B₄C ~10% harder, but both defeat high-velocity rounds |
| Density | 3.15 g/cm³ | 2.50 g/cm³ | B₄C lighter, but SiC weight difference is minimal in plate form |
| NIJ Level IV Capability | Yes (high-velocity threats) | Yes (high-velocity threats) | Both meet the same threat standard |
| Raw Material Cost | $15-25 / kg | $80-120 / kg | SiC: 75-85% Cheaper Raw Material |
| Finished Plate Cost | 65-85 USD | 120-180 USD | SiC: 35-45% Savings |
| Supply Chain Stability | Mature, widely available | Limited suppliers globally | SiC: Better Availability |
The HB-SIC-4M-1012 monolithic Silicon Carbide plate is engineered for procurement officers who need NIJ Level IV protection at scale. Boron Carbide may offer marginally higher hardness and slightly lower weight, but the 35-45% cost premium is rarely justified for standard-issue equipment. Our SiC monolithic design achieves the same high-velocity threat defeat with a supply chain you can count on.
Key Features
- NIJ 0101.06 Level IV Certified: Defeats high-velocity threats at 2,880 fps (878 m/s)
- Monolithic 10.2mm SiC Strike Face: Single-piece ceramic eliminates bonding failure points found in multi-tile designs
- UHMWPE Composite Laminate Backing: Multi-layer backing optimizes energy absorption while keeping backface deformation under 25mm
- Swimmer Cut Profile: Reduced shoulder profile for better equipment handling and vehicle mobility
- Consistent 2-Round High-Velocity Multi-Hit: Tested per NIJ 0101.06 protocol with high-velocity projectiles
Who Should Choose SiC Over B₄C?
- Protection units outfitting large-scale organizational protection on a fixed budget
- Law enforcement agencies equipping patrol officers
- Private security contractors needing reliable Level IV protection at scale
- Distributors seeking high-margin ceramic armor with reliable factory supply
Stop paying the Boron Carbide premium. Get NIJ Level IV protection at a sensible price. Inquire now for volume discounts and OEM options.
