Pressureless Sintered Boron Carbide R400 Ballistic Tile 50x50x9mm NIJ Level IV Standalone Armor Ceramic Insert
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | High Broad |
| Certification: | ISO 9001:2015, NIJ 0101.06 |
| Model Number: | HB-BT-B4C-5050-9-IV |
| Document: | SIC Ballistic Armor Tiles-P...ad.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500 Pieces |
|---|---|
| Price: | USD 0.1-5 / Piece |
| Packaging Details: | HB branded export-grade corrugated carton with multi-layer EPE foam interleaving and vacuum-sealed moisture barrier bag |
| Delivery Time: | 5-7 working days for stock, 15-30 days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 3000000 Pieces per Month |
|
Detail Information |
|||
| Tile Dimensions: | 50 X 50 X 9 Mm | Elastic Modulus: | ≥ 440 GPa |
|---|---|---|---|
| Fracture Toughness: | 2.8-3.2 MPa·m1/2 | Density: | 2.50 ± 0.03 G/cm3 |
| Flexural Strength: | ≥ 350 MPa (4-point) | Vickers Hardness: | ≥ 3000 HV1 |
| Highlight: | Boron Carbide R400 Ballistic Tile,NIJ Level IV Standalone Armor,Ultra-Lightweight Ceramic Plate |
||
Product Description
Representing the pinnacle of ceramic armor materials, this boron carbide R400 ballistic tile combines extreme hardness with the lightest weight in its class. Our pressureless sintering process for B4C R400 grade achieves near-theoretical density without the prohibitive cost of hot isostatic pressing.
- Industry-Leading Hardness: Vickers hardness exceeding 3000 HV1, surpassed only by diamond and cubic boron nitride, ensures reliable defeat of armor-piercing projectiles
- Ultra-Low Density 2.50 g/cm³: 20% lighter than silicon carbide and 35% lighter than alumina, enabling armor systems under 2.5 kg/ft² for Level IV protection
- R400 Grade Optimization: Controlled carbon-to-boron ratio with sub-micron particle size distribution enhances sinterability while preserving ballistic-grade hardness
- Pressureless Sintering Innovation: Proprietary sintering aid formulation enables full densification at atmospheric pressure, avoiding the high capital cost and size limitations of hot-press tooling
| Threat | Projectile | Velocity | Result |
|---|---|---|---|
| NIJ Level IV | 30-06 M2 AP | 878 ± 9 m/s | ✓ Stop (Standalone) |
| M855A1 | 5.56x45mm M855A1 EPR | 945 ± 15 m/s | ✓ Stop (with UHMWPE backing) |
Our B4C R400 tiles are manufactured using advanced pressureless sintering technology that delivers consistent microstructure across the entire batch. Unlike hot-pressed boron carbide which suffers from density gradients near die edges, pressureless sintered tiles exhibit uniform properties throughout, reducing scrap rate and improving ballistic predictability.
This premium tile is the material of choice for special operations forces, law enforcement tactical teams, and helicopter/aircraft armor where every gram counts. The square format enables modular array assembly for compound-curve torso plates via advanced bonding techniques.
