Pressureless Sintered Silicon Carbide Ballistic Tile 100x100x9mm NIJ Level III Multi-Hit Armor Plate
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | High Broad |
| Certification: | ISO 9001:2015, NIJ 0101.06 |
| Model Number: | HB-BT-SIC-100100-9-III |
| Document: | SIC Ballistic Armor Tiles-P...ad.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 300 Pieces |
|---|---|
| Price: | USD1-10 / Piece |
| Packaging Details: | HB branded reinforced export carton with custom-cut EPE foam tray inserts and vacuum-sealed moisture barrier |
| Delivery Time: | 5-7 working days for stock, 15-30 days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 30000 Pieces per Month |
|
Detail Information |
|||
| Tile Dimensions: | 100 X 100 X 9 Mm | Ballistic Protection Level: | NIJ Level III Multi-Hit (7.62x51mm M80 X3) |
|---|---|---|---|
| Elastic Modulus: | ≥ 400 GPa | Fracture Toughness: | 3.5-4.0 MPa·m1/2 |
| Flexural Strength: | ≥ 380 MPa (4-point) | Vickers Hardness: | ≥ 2600 HV1 |
| Highlight: | Large Format SiC Ballistic Tile,Multi-Hit Level III Ceramic,Pressureless Sintered Armor Plate |
||
Product Description
Pressureless Sintered Silicon Carbide Ballistic Tile 100x100x9mm NIJ Level III Large Format Multi-Hit Armor Plate
This 100x100mm large format pressureless sintered silicon carbide ballistic tile is designed for armor applications where joint-line minimization is critical to overall array performance. The 4x larger footprint versus standard 50mm tiles reduces mosaic joint count by 75%, significantly improving multi-hit ballistic integrity.
Large Format Advantages
- Reduced Joint Density: Fewer tile-to-tile interfaces mean fewer weak points where projectiles can exploit edge effects, improving overall array V50 performance
- Simplified Assembly: Fewer tiles to position and bond during armor panel fabrication, reducing labor cost and assembly time
- Pressureless Sintering Scalability: Unlike hot-pressing which is limited by die dimensions, our pressureless sintering furnaces accommodate large-format tiles up to 200x200mm
- Consistent Flatness: Advanced sag control during sintering maintains surface flatness ≤ 0.2 mm across the full 100mm span
Multi-Hit Ballistic Performance
| Test Condition | Projectile | Shot Spacing | Result |
|---|---|---|---|
| 3-Shot Multi-Hit | 7.62x51mm M80 Ball | 50mm triangle | ✓ All 3 Stopped |
Production Technology
Our pressureless sintering process enables cost-effective production of large format ceramic armor tiles without the inherent size constraints of hot-press tooling. The isotropic sintering shrinkage is precisely compensated in green-body design, delivering final dimensions within ±0.3mm tolerance across the 100mm span.
Contact Information
Jane Hu
China Hunan High Broad New Material Co., Ltd.
70 Chezhan North Road, Changsha, China 410100
Mobile/Whatsapp: +86-139-7515-2932
Wechat: 139-7515-2932
Skype: jane.hu261
QQ: 122367362
Email: janehu@hbnewmaterial.com
Quality Control
Each tile is inspected with 3D laser profilometry for flatness, ultrasonic C-scan for internal integrity, and undergoes statistical ballistic lot acceptance testing (LAT). Certificate of Analysis provided with every batch.
