Pressureless Sintered Boron Carbide R400 Ballistic Tile 100x100x10mm NIJ Level IV Large Format Armor Insert
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | High Broad |
| Certification: | ISO 9001:2015, NIJ 0101.06 |
| Model Number: | HB-BT-B4C-100100-10-IV |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Pieces |
|---|---|
| Price: | USD 1-10 / Piece |
| Packaging Details: | HB branded reinforced export carton with custom-cut EPE foam tray inserts and vacuum-sealed moisture barrier |
| Delivery Time: | 5-7 working days for stock, 15-30 days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 20000 Pieces per Month |
|
Detail Information |
|||
| Tile Dimensions: | 100 X 100 X 10 Mm | Elastic Modulus: | ≥ 440 GPa |
|---|---|---|---|
| Fracture Toughness: | 2.8-3.2 MPa·m1/2 | Flexural Strength: | ≥ 350 MPa (4-point) |
| Vickers Hardness: | ≥ 3000 HV1 | Density: | 2.50 ± 0.03 G/cm3 |
| Highlight: | B4C R400 Large Format Tile,Level IV Lightweight Armor,Pressureless Sintered Boron Carbide |
||
Product Description
Pressureless Sintered Boron Carbide R400 Ballistic Tile 100x100x10mm NIJ Level IV Large Format Armor Insert
Large Format B4C R400 Ballistic Tile 100x100x10mm - NIJ Level IV
This large format boron carbide R400 ballistic tile delivers the ultimate Level IV protection in a size format previously achievable only with alumina or SiC. Our breakthrough pressureless sintering process for B4C R400 overcomes the traditional 50mm size limitation of hot-pressed boron carbide, opening new armor design possibilities.
Breakthrough: Large B4C Tiles via Pressureless Sintering
- Overcomes Hot-Press Limits: Traditional hot-pressed B4C is restricted to ~50mm square due to die size and pressure uniformity constraints. Pressureless sintering frees tile dimensions from die geometry
- Uniform Density at Scale: Consistent 2.50 g/cm3 density across all 100mm tile area, verified by multi-point Archimedes testing per batch
- Cost-Effective Level IV: Eliminating graphite tooling wear and single-cavity hot-press cycles reduces manufacturing cost by 40-50% per tile
- Aerospace-Grade Performance: This tile is specified for helicopter and fixed-wing aircraft armor where weight savings translate directly to payload capacity and fuel efficiency
Ballistic Performance Overview
| Threat Level | Projectile | Areal Density | Status |
|---|---|---|---|
| NIJ Level IV | 30-06 M2 AP | ~35 kg/m² (with backing) | ✓ Standalone |
| VPAM 11 | 7.62x51mm AP (WC) | ~35 kg/m² (with backing) | ✓ Available |
Aerospace Armor Applications
The combination of large tile format and ultra-low density makes this B4C R400 tile ideal for helicopter floor armor panels, cockpit seat protection, and critical aircraft subsystem shielding. Reduced joint density enhances multi-hit capability against sustained small-arms fire scenarios.
Contact US
Jane Hu
China Hunan High Broad New Material Co., Ltd.
70 Chezhan North Road, Changsha, China 410100
Mobile/Whatsapp: +86-139-7515-2932
Wechat: 139-7515-2932
Skype: jane.hu261
QQ: 122367362
Email: janehu@hbnewmaterial.com
Manufactured under ISO 9001:2015 quality management system. Ballistic testing per NIJ 0101.06 / STANAG 4569 standards. Full material certification with each shipment including density, hardness, and ultrasonic inspection reports.
