150x150mm Pressureless Sintered Silicon Carbide Ballistic Tile with NIJ Level III+ Protection for Armor Plates
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | High Broad |
| Certification: | ISO 9001:2015, NIJ 0101.06 |
| Model Number: | WN-BT-SIC-150150-10-III+ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Pieces |
|---|---|
| Price: | USD 25-80 / Piece |
| Packaging Details: | WNRLN branded reinforced export carton with custom-cut EPE foam tray and vacuum-sealed moisture barrier |
| Delivery Time: | 5-7 working days for stock, 15-30 days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 20000 Pieces per Month |
|
Detail Information |
|||
| Tile Dimensions: | 150 X 150 X 10 Mm | Elastic Modulus: | ≥ 400 GPa |
|---|---|---|---|
| Fracture Toughness: | 3.5-4.0 MPa·m1/2 | Flexural Strength: | ≥ 380 MPa (4-point) |
| Vickers Hardness: | ≥ 2600 HV1 | Density: | 3.13 ± 0.03 G/cm3 |
| Highlight: | Large SiC Special Threat Tile,M855 M193 Protection Plate,Pressureless Sintered Level III Plus |
||
Product Description
This 150x150mm extra-large format pressureless sintered silicon carbide ballistic tile provides superior single-tile coverage for fixed-position and vehicle armor applications. The expansive tile area reduces the number of tiles required per armor panel by 89% versus standard 50mm tiles, dramatically simplifying assembly while improving overall ballistic integrity.
- 225 cm² Coverage per Tile: Each tile covers 2.25x the area of a 100mm tile, enabling rapid armor panel construction with 1/9th the number of components versus 50mm mosaic arrays
- Proven M855/M193 Protection: Engineered for Level III+ special threat protection, defeating both 5.56x45mm M855 (SS109 green tip) and M193 lead-core at full velocities with multi-hit capability
- Pressureless Sintering at Scale: Our production furnaces accommodate 150x150mm tiles without the warpage and density gradients that plague hot-pressed tiles at this size, delivering consistent ±0.03 g/cm³ density uniformity
- Cost-Effective Large Format: Eliminating 8 out of 9 tile-to-tile bond lines per armor panel saves not only tile handling labor but also reduces adhesive consumption and assembly quality risks
| Threat | Projectile | Velocity | Result |
|---|---|---|---|
| M855 Green Tip | 5.56x45mm M855 (SS109) | 945 ± 15 m/s | ✓ Stop |
| M193 Lead Core | 5.56x45mm M193 | 990 ± 15 m/s | ✓ Stop |
| 7.62x39mm API | 7.62x39mm API BZ | 730 ± 15 m/s | ✓ Stop (with backing) |
This large format tile is optimized for static and semi-mobile armor applications including checkpoint barriers, guard post cladding, embassy perimeter hardening, riot shield inserts, and light vehicle door panels. The reduced joint count is especially critical for fixed-position armor where ballistic predictability over extended engagement periods is paramount.
Bulk Supply Ready: Production capacity of 20,000 tiles per month with ability to scale. Custom thickness from 8mm to 14mm available for elevated threat levels. Technical data package and ballistic test reports provided with initial qualification order.
