50x50mm Pressureless Sintered Silicon Carbide Ceramic Tile with Protective Polymer Coating for Ballistic Protection
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | OEM |
| Certification: | ISO 9001:2015 |
| Model Number: | SiC-SQ-50-C |
| Document: | SIC Ballistic Armor Tiles-P...ad.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Pieces |
|---|---|
| Price: | USD0.1-2 / Piece |
| Packaging Details: | Custom foam tray with individual cell packing, anti-static protection, export-grade corrugated carton |
| Delivery Time: | 10-18 working days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 2500000 Pieces per Month |
|
Detail Information |
|||
| Sintering Method: | Pressureless Sintered | Hardness: | >=2500 HV (Vickers) |
|---|---|---|---|
| Thickness: | 5-12 Mm (Customizable) | Flexural Strength: | >=380 MPa |
| Dimensions: | 50 X 50 Mm | Density: | >=3.10 G/cm3 (Base Material) |
| Highlight: | Coated SiC Ceramic Square Tile,Enhanced Multi-Hit Ballistic Plate,50x50mm Surface Treated Ceramic |
||
Product Description
Silicon Carbide Ceramic Ballistic Square Tile 50x50mm with Surface Coating Enhanced Multi-Hit Protection
Product Overview
Silicon carbide (SiC) ceramic square tile in 50 x 50 mm format, manufactured via pressureless sintering for superior density uniformity and mechanical consistency. Ideal for ballistic protection panel assembly.
Key Features
- Base Material: Pressureless sintered silicon carbide (SiC), density >=3.10 g/cm³
- Surface Treatment: Protective polymer coating for fragmentation control
- Dimensions: 50 x 50 mm square tile, custom thickness 5-12 mm
- Hardness: >=2500 HV (Vickers)
- Flexural Strength: >=380 MPa
- Coating enhances multi-hit performance and reduces spall
- Available in black or olive green coating
Technical Specifications
| Ceramic Core Properties | |
| Material | Silicon Carbide (SiC), >=98.5% Purity |
| Sintering Method | Pressureless Sintered |
| Density | >=3.10 g/cm³ |
| Hardness (Vickers) | >=2500 HV |
| Flexural Strength | >=380 MPa |
| Fracture Toughness | 3.5-4.0 MPa.m¹/² |
| Coating Properties | |
| Coating Type | Elastomeric Polymer |
| Coating Thickness | 0.3-0.8 mm (per surface) |
| Function | Fragmentation containment, impact energy absorption |
