50x50mm Pressureless Sintered Silicon Carbide Ceramic Tile with >=99.0% SiC Purity for Ballistic Protection Plate
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | OEM |
| Certification: | ISO 9001:2015 |
| Model Number: | SiC-SQ-50-HP |
| Document: | SIC Ballistic Armor Tiles-P...ad.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Pieces |
|---|---|
| Price: | USD 0.1-1 / Piece |
| Packaging Details: | Custom foam tray with individual cell packing, anti-static moisture-proof barrier, export-grade carton |
| Delivery Time: | 10-18 working days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 20000000 Pieces per Month |
|
Detail Information |
|||
| Fracture Toughness: | 3.8-4.2 MPa.m1/2 | Sintering Method: | Pressureless Sintered |
|---|---|---|---|
| Flexural Strength: | >=400 MPa | SiC Purity: | >=99.0% |
| Hardness: | >=2600 HV (Vickers) | Dimensions: | 50 X 50 Mm |
| Highlight: | High Purity SiC Ceramic Tile,Premium Grade Ballistic Plate,50x50mm Square Protection Insert |
||
Product Description
High Purity Silicon Carbide Ceramic Square Ballistic Tile 50x50mm Premium Grade Protection Plate OEM
Key Features
- High Purity: >=99.0% SiC content with controlled sintering aids
- Enhanced Density: >=3.12 g/cm³ for superior volumetric efficiency
- Premium Hardness: >=2600 HV (Vickers), 4% above standard grade
- Flexural Strength: >=400 MPa with tighter standard deviation
- Dimensions: 50 x 50 mm square, thickness 5-12 mm customizable
- Low Porosity: <=0.3% for maximum structural integrity
- Consistent batch performance verified by ultrasonic C-scan inspection
Technical Specifications
| Material | High Purity Silicon Carbide (SiC) |
|---|---|
| SiC Content | >=99.0% |
| Sintering Method | Pressureless Sintered |
| Density | >=3.12 g/cm³ |
| Hardness (Vickers) | >=2600 HV |
| Flexural Strength | >=400 MPa |
| Fracture Toughness | 3.8-4.2 MPa.m¹/² |
| Porosity | <=0.3% |
| Elastic Modulus | >=410 GPa |
