30x30mm Boron Carbide Ceramic Hexagonal Tile with Aramid Composite Backing for Ballistic Protection
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | OEM |
| Certification: | ISO 9001:2015 |
| Model Number: | B4C-HEX-30-B |
| Document: | Performance Comparison of P...)1.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Pieces |
|---|---|
| Price: | USD 0.1-2 / Piece |
| Packaging Details: | Individual foam cell packing with moisture-proof anti-static barrier, export-grade corrugated carton, palletized |
| Delivery Time: | 12-22 working days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 12000 Pieces per Month |
|
Detail Information |
|||
| Sintering Method: | Pressureless Sintered | Hardness: | >=3000 HV (Vickers) |
|---|---|---|---|
| Total Thickness: | 6-14 Mm (with Backing) | Flexural Strength: | >=350 MPa |
| Dimensions: | 30 X 30 Mm (Flat-to-Flat) | Density: | >=2.48 G/cm3 (Ceramic Core) |
| Highlight: | B4C Hexagon with Composite Backing,Ultra-Light Hexagonal Protection Tile,30x30mm Backed Boron Carbide Insert |
||
Product Description
Boron Carbide Ceramic Hexagonal Ballistic Tile 30x30mm with Composite Backing Ultra-Light Protection Insert
Product Overview
Boron carbide (B4C) ceramic hexagonal tile in 30 x 30 mm (Flat-to-Flat) format, manufactured via pressureless sintering for superior density uniformity and mechanical consistency. Ideal for ballistic protection panel assembly.
Key Features
- Ceramic: Pressureless sintered B4C, hardness >=3000 HV, density >=2.48 g/cm³
- Backing: Aramid fiber composite, high-toughness structural adhesive bond
- Shape: Regular hexagonal, 30x30mm flat-to-flat for optimal tessellation
- Total thickness: 6-14 mm, customizable ceramic-to-backing ratio
- Lowest areal density achievable for the given protection level
- Minimum inter-tile gap geometry eliminates straight-line weak paths
Jane Hu
China Hunan High Broad New Material Co., Ltd.
70 Chezhan North Road, Changsha, China 410100
Mobile/Whatsapp: +86-139-7515-2932
Wechat: 139-7515-2932
Skype: jane.hu261
QQ: 122367362
Email: janehu@hbnewmaterial.com
70 Chezhan North Road, Changsha, China 410100
Mobile/Whatsapp: +86-139-7515-2932
Wechat: 139-7515-2932
Skype: jane.hu261
QQ: 122367362
Email: janehu@hbnewmaterial.com
Technical Specifications
| Ceramic Core | |
| Material | Boron Carbide (B4C) |
|---|---|
| Sintering Method | Pressureless Sintered |
| Density | >=2.48 g/cm³ |
| Hardness | >=3000 HV (Vickers) |
| Flexural Strength | >=350 MPa |
| Fracture Toughness | 2.5-3.0 MPa.m¹/² |
| Backing Layer | |
| Material | Aramid Fiber Composite |
| Bonding | High-Strength Structural Adhesive |
Want to Know more details about this product
