Ultra-Lightweight Boron Carbide Ballistic Tile with 2.50g/cm3 Density and Custom Thickness for OEM Applications
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | High Broad |
| Certification: | ISO 9001:2015 |
| Model Number: | HB-B4C-HP-002 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 KGS |
|---|---|
| Price: | According to quantity and specification |
| Packaging Details: | Export-grade plywood case with custom foam cushioning, vacuum-sealed inner packaging |
| Delivery Time: | 7-25 working days depending on order volume |
| Payment Terms: | T/T,L/C,Western Union,PayPal |
| Supply Ability: | 50000 Pieces per Month |
|
Detail Information |
|||
| Density: | 2.48-2.52 G/cm3 | Compressive Strength: | >=2800 MPa |
|---|---|---|---|
| Available Thickness: | 4mm To 12mm | Maximum Temperature: | 600 C |
| Fracture Toughness: | >=3.5 MPa.m1/2 | Vickers Hardness: | >=3000 HV |
| Highlight: | Hot Pressed Boron Carbide Tile,Ultra Lightweight Ceramic Plate,Rectangular Ballistic Protection Tile |
||
Product Description
Our hot pressed boron carbide (B₄C) ceramic tiles represent the pinnacle of lightweight ballistic protection technology. With a density of just 2.50 g/cm³—approximately 30 percent lighter than silicon carbide—B₄C delivers unmatched protective performance per unit weight.
- Ultra-Lightweight: Density of only 2.48-2.52 g/cm³, ideal for weight-sensitive applications
- Extreme Hardness: Vickers hardness exceeding 3000 HV, second only to diamond and cubic boron nitride
- Superior Specific Stiffness: Excellent elastic modulus-to-density ratio for structural rigidity
- Neutron Absorption: High boron content provides inherent neutron shielding capability
- Combined Protection: Excellent for applications requiring both ballistic and radiation shielding
The hot pressing process ensures near-theoretical density with minimal porosity, resulting in consistent mechanical properties and superior ballistic performance. Each tile undergoes precise dimensional control during the sintering cycle.
We provide fully customized rectangular plates in any dimension. Standard offerings from 100×150mm up to 300×300mm, with thickness from 4mm to 12mm. Multi-curve, single-curve, and angled profiles can be produced to customer specifications. OEM drawing-based manufacturing is our specialty.
- Personal wearable protective systems
- Aerospace component shielding
- Rotary-wing aircraft protective panels
- Maritime security installations
- Critical infrastructure protection
Every production batch undergoes density verification, ultrasonic flaw detection, and dimensional inspection. Full material traceability with chemical analysis certificates provided. ISO 9001:2015 certified production facility.
