Pressureless Sintered Silicon Carbide Ceramic Tile 100x100x6mm Square Shape Ballistic Armor Plate
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | OEM |
| Certification: | ISO 9001:2015 |
| Model Number: | SiC-SQ-100-6 |
| Document: | SIC Ballistic Armor Tiles-P...ad.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Pieces |
|---|---|
| Price: | USD 0.1-2 / Piece |
| Packaging Details: | Custom foam tray with individual cell packing, anti-static moisture-proof barrier, export-grade carton |
| Delivery Time: | 10-18 working days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 20000000 Pieces per Month |
|
Detail Information |
|||
| Flexural Strength: | ≥400 MPa | Thickness: | 6 Mm (standard), 2-100 Mm Custom |
|---|---|---|---|
| Compressive Strength: | ≥2500 MPa | Tile Size: | 100 X 100 Mm |
| Density: | ≥3.10 G/cm3 | Fracture Toughness: | 3.8-4.2 MPa.m1/2 |
| Highlight: | 100x100mm Square SiC Tile,6mm Thickness Armor Ceramic,Pressureless Sintered Ballistic Plate |
||
Product Description
Pressureless Sintered Silicon Carbide Ceramic Tile 100x100x6mm Square Shape Ballistic Armor Plate Insert
Key Features
- Pressureless sintered silicon carbide (SiC) ceramic tile, 100 x 100 mm square format
- Standard thickness 6 mm, custom thickness from 2 mm to 100 mm available
- SiC purity ≥99.0% with uniform dense microstructure
- Square geometry delivers high per-tile coverage and simple panel assembly
- Consistent dimensional tolerance for tight edge-to-edge layup
- OEM customization for thickness, edge chamfer, and surface finish
- Square format with straight edges for gap-free panel assembly
Technical Specifications
| Property | Value |
|---|---|
| Material | Pressureless Sintered Silicon Carbide (SiC) |
| Shape | Square |
| Tile Size | 100 x 100 mm |
| Thickness | 6 mm (standard), 2-100 mm (custom) |
| SiC Purity | ≥99.0% |
| Density | ≥3.10 g/cm³ |
| Hardness | ≥2600 HV (Vickers) |
| Flexural Strength | ≥400 MPa |
| Compressive Strength | ≥2500 MPa |
| Fracture Toughness | 3.8-4.2 MPa·m¹/² |
| Sintering Method | Pressureless Sintered |
Size and Shape Comparison
| Configuration | Per-Tile Coverage | Assembly | Typical Use |
|---|---|---|---|
| Square 100x100mm | 10000 mm² | Fewer joints, fast layup | Flat armor panels, vehicle armor |
| Square 50x50mm | 2500 mm² | Compact module, curve friendly | Body armor inserts, curved panels |
| Hexagonal SW30-50mm | ~779-2165 mm² | Tessellated, no straight seams | Multi-hit body armor |
Available Thickness Options (mm)
| Thickness | Typical Application | Weight Characteristic |
|---|---|---|
| 2-3 mm | Ultra-thin flexible vest inserts | Minimum weight |
| 4-4.1 mm | Lightweight body armor panels | Very light |
| 5-6 mm | Standard body armor strike face | Balanced |
| 7-8 mm | Enhanced multi-hit protection | Moderate |
| 9-10 mm | High-threat personal protection | Heavier |
| 13-16 mm | Vehicle / boat armor panels | Heavy duty |
| Up to 100 mm | Custom engineering armor | Custom |
Material Comparison
| Property | SiC (This Product) | Al2O3 | B4C |
|---|---|---|---|
| Density | ≥3.10 g/cm³ | ≥3.60 g/cm³ | ≥2.48 g/cm³ |
| Hardness | ≥2600 HV | ≥1500 HV | ≥3000 HV |
| Flexural Strength | ≥400 MPa | ≥300 MPa | ≥350 MPa |
| Fracture Toughness | 3.8-4.2 MPa·m¹/² | 3.0-3.5 MPa·m¹/² | 2.5-3.0 MPa·m¹/² |
| Relative Cost | Medium | Low | High |
| Balance Rating | Best overall balance | Budget option | Lightest option |
Selection Guide
- Choose Square 100x100mm: Maximum per-tile coverage, fewer joints, faster panel production.
- Choose Square 50x50mm: Compact module size, easier curved-panel fitting, finer damage containment.
- Choose Hexagonal: Tessellated layout without continuous straight gaps for enhanced multi-hit performance.
- Thicker tiles (9 mm+): Higher threat level resistance for vehicle and fixed installation armor.
