Pressureless Sintered Silicon Carbide Ceramic Tile 100x100x20mm Ballistic Armor Plate with ≥99.0% SiC Purity
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | OEM |
| Certification: | ISO 9001:2015 |
| Model Number: | SiC-SQ-100-20 |
| Document: | SIC Ballistic Armor Tiles-P...ad.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Pieces |
|---|---|
| Price: | USD 0.1-2 / Piece |
| Packaging Details: | Custom foam tray with individual cell packing, anti-static moisture-proof barrier, export-grade carton |
| Delivery Time: | 10-18 working days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 20000000 Pieces per Month |
|
Detail Information |
|||
| Thickness: | 20mm (custom 2mm-100mm) | Density: | ≥3.10 G/cm3 |
|---|---|---|---|
| Flexural Strength: | ≥400 MPa | SiC Purity: | ≥99.0% |
| Compressive Strength: | ≥2500 MPa | Fracture Toughness: | 3.8-4.2 MPa.m1/2 |
| Highlight: | 100x100x20mm SiC Tile,20mm Heavy Ballistic Ceramic,Thick Square Armor Plate |
||
Product Description
Pressureless Sintered Silicon Carbide Square Ceramic Tile 100x100x20mm Heavy Duty Ballistic Armor Plate
100x100mm heavy duty silicon carbide square ceramic tile in 20mm thickness for high-threat ballistic armor plates. The extra thick section combined with wide square coverage delivers maximum protection in a modular ceramic format.
Key Features
- Pressureless sintered silicon carbide (SiC), square 100x100mm format
- 20mm heavy duty thickness, custom 2mm to 100mm available
- SiC purity ≥99.0% with dense uniform microstructure
- Extra thick section for maximum single-layer protection
- Wide square format with simple assembly
- OEM customization for size and finish
Technical Specifications
| Material | Pressureless Sintered Silicon Carbide (SiC) |
| Shape | Square 100x100mm |
| Thickness | 20mm standard / 2mm-100mm custom |
| Hardness | ≥2600 HV (Vickers) |
| Density | ≥3.10 g/cm³ |
| Flexural Strength | ≥400 MPa |
| Compressive Strength | ≥2500 MPa |
| Fracture Toughness | 3.8-4.2 MPa·m¹/² |
| SiC Purity | ≥99.0% |
Available Sizes (Custom Thickness 2mm to 100mm)
| Shape / Size | Typical Advantage |
|---|---|
| Square 50x50mm | Compact module, curved panel fitting, fine damage containment |
| Square 100x100mm ★ | Wide coverage, fewer joints, fast panel assembly |
| Hex SW20mm | Smallest hex module, maximum mosaic flexibility |
| Hex SW30mm | Balanced hex size for standard mosaic layup |
| Hex SW40mm | Larger hex tile, faster assembly, good contour adaptability |
| Hex SW60mm | Big hex coverage for flat protection panels |
| Hex SW80mm | Largest hex format, minimum joints for flat armor |
SiC vs B4C Selling Point Comparison
| Property | SiC (Silicon Carbide) | B4C (Boron Carbide) |
|---|---|---|
| Areal Density (Weight) | ≥3.10 g/cm³ · Heavier | ≥2.48 g/cm³ · Lightest |
| Hardness | ≥2600 HV | ≥3000 HV |
| Flexural Strength | ≥400 MPa | ≥350 MPa |
| Fracture Toughness | 3.8-4.2 MPa·m¹/² | 2.5-3.0 MPa·m¹/² |
| Multi-Hit Performance | Excellent (tessellated mosaic) | Good |
| Cost Efficiency | Medium · Best value | High · Premium |
| Best Choice For | Balanced protection and budget | Lightest weight requirement |
Selection Guide
- 20mm heavy tiles are specified for high-threat protection requirements
- Wide 100x100mm coverage reduces joint count in large panels
- This tile demonstrates the thick end of the 2mm-100mm custom range
