Ceramic Lined Sandblasting Nozzle with 6mm Bore and 40mm Length for High Impact Surface Prep
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | High Broad |
| Certification: | ISO 9001:2015 |
| Model Number: | SBN-SB-0640 |
| Document: | Venturi nozzle Jane.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 Pieces |
|---|---|
| Price: | USD 5-10 / Piece |
| Packaging Details: | Color box with shock-proof foam insert, export-grade corrugated carton |
| Delivery Time: | 3 working days for stock, 15-25 days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 20000 Pieces per Month |
|
Detail Information |
|||
| Overall Length: | 40mm | Material: | Ceramic Lined |
|---|---|---|---|
| Max Temperature: | 1200 C | Bending Strength: | > 400 MPa |
| Connection: | Aluminum Jacket, 1-1/4 Inch Thread | Bore Diameter: | 6mm |
| Highlight: | Sandblasting Straight Bore Nozzle,6mm Ceramic Lined Nozzle,Surface Prep Blast Nozzle |
||
Product Description
Sandblasting Straight Bore Nozzle 6mm Bore 40mm Length Ceramic Lined for Surface Prep
Model: SBN-SB-0640
This sandblasting straight bore nozzle with ceramic lining delivers a concentrated abrasive stream for surface preparation and coating removal. The straight bore focuses media for powerful cleaning on flat surfaces.
Key Features
- Straight bore for a concentrated, high impact stream
- Ceramic lining resists abrasive wear
- Precision ground 6mm bore for stable flow
- Uniform coverage for surface preparation
- Reliable performance in workshop conditions
Technical Specifications
| Model Number | SBN-SB-0640 |
| Material | Ceramic Lined |
| Hardness | HRA 88-92 (Mohs 9.3) |
| Density | 2.48 g/cm³ |
| Bending Strength | > 400 MPa |
| Bore Diameter | 6mm |
| Overall Length | 40mm |
| Outer Diameter | 24mm |
| Connection | Aluminum jacket, 1-1/4 inch thread |
| Max Working Temperature | 1200°C |
| Service Life | 800-1000 hours |
| MOQ | 10 pieces |
Material Comparison
| Property | Boron Carbide B4C | Tungsten Carbide | Silicon Carbide | Alumina Ceramic |
|---|---|---|---|---|
| Hardness (Mohs) | 9.3 | 9.0 | 9.2 | 8.5 |
| Density (g/cm³) | 2.48 | 14.8 | 3.12 | 3.60 |
| Relative Service Life | 5.0x | 3.5x | 2.5x | 1.0x |
| Max Working Temp (°C) | 1200 | 1000 | 1400 | 1500 |
| Best Application | Heavy duty blasting | General blasting | Medium duty | Light duty |
Nozzle Type Comparison
| Criterion | Straight Bore Nozzle | Venturi Nozzle |
|---|---|---|
| Cost | Lower | Higher |
| Focus | Concentrated stream | Wide spray |
| Best For | Deep cleaning and cutting | Surface finishing |
Application Scenarios
| Application | Description |
|---|---|
| Surface preparation | Substrate prep before painting |
| Coating removal | Paint, primer and rust stripping |
| Metal cleaning | Weld and fabrication cleaning |
| Floor prep | Concrete and steel floor treatment |
Why Choose Our Nozzle
- Factory direct pricing with stable bulk supply
- Strict dimensional inspection on every nozzle
- OEM and custom bore sizes available
- Fast lead time for both stock and production orders
Send us your bore size, quantity and application details to receive a tailored quotation and a free sample for testing.
