Hot Pressed Boron Carbide Venturi Sandblasting Nozzle 35x6mm B4C Ceramic Blast Tip for High Wear Resistance
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | High Broad |
| Certification: | ISO 9001:2015 |
| Model Number: | B4C-V35-06 |
| Document: | Venturi nozzle Jane.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 Pieces |
|---|---|
| Price: | USD5-25 / Piece |
| Packaging Details: | Individual foam-lined box with silica gel desiccant, export-grade master carton |
| Delivery Time: | 3-5 working days for stock, 10-20 days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 10000 Pieces per Month |
|
Detail Information |
|||
| Nozzle Type: | Venturi | Max Operating Temperature: | 600°C |
|---|---|---|---|
| Hardness: | ≥ 2800 HV (Mohs 9.3) | Density: | ≥ 2.48 G/cm³ |
| Length: | 35mm | Orifice Diameter: | 6mm |
| Highlight: | Hot Pressed B4C Venturi Nozzle,Sandblasting Boron Carbide Tip,Ceramic Blast Nozzle 35x6mm |
||
Product Description
The B4C-V35-06 is a precision-engineered venturi-type sandblasting nozzle manufactured from hot pressed boron carbide (B4C), one of the hardest ceramic materials available for industrial blast applications. With a Mohs hardness of 9.3, B4C is surpassed only by cubic boron nitride and diamond, making it the ideal material for high-wear blast nozzle applications.
Unlike conventional silicon carbide (SiC) nozzles that rely on reaction bonding or pressureless sintering, our hot pressed B4C nozzles achieve near-theoretical density (≥2.48 g/cm³) through simultaneous application of high temperature (2100-2200°C) and uniaxial pressure during manufacturing. This results in:
- 3-5x longer service life compared to silicon carbide nozzles under identical blasting conditions
- Superior wear resistance due to the elimination of micro-porosity inherent in pressureless sintered ceramics
- Consistent bore geometry throughout the entire service life, maintaining precise blast pattern and velocity
- Higher thermal shock resistance than SiC, reducing cracking from rapid temperature cycling
The venturi geometry of the B4C-V35-06 accelerates abrasive particles to velocities up to 200 m/s, significantly higher than straight bore nozzles. This provides:
- 30-40% higher blasting productivity compared to straight bore nozzles of equivalent orifice size
- More uniform abrasive distribution across the blast pattern
- Reduced air consumption per unit area cleaned
| Material | Hot Pressed Boron Carbide (B4C) |
| Type | Venturi |
| Orifice | 6mm |
| Length | 35mm |
| Density | ≥ 2.48 g/cm³ |
| Hardness | ≥ 2800 HV / Mohs 9.3 |
| Max Temperature | 600°C |
Ideal for surface preparation, rust removal, paint stripping, and descaling operations using aluminum oxide, silicon carbide, garnet, or steel grit abrasives. Suitable for use with all standard sandblasting equipment and blast cabinets.
Contact us today for volume pricing and complementary wear-life testing data comparing B4C vs SiC and WC nozzles.
