MMO Coated Titanium Ribbon Flexible Anode with 6.35mm Width and Iridium-Tantalum Mixed Metal Oxide Coating for 25 Years Design Life
Product Details:
| Place of Origin: | Shaanxi, China |
| Brand Name: | YLK |
| Certification: | ISO 9001:2015, ISO 14001:2015 |
| Model Number: | MMO-R-6.35-CON |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Meters |
|---|---|
| Price: | USD 3.50-12.00 / Meter |
| Packaging Details: | Export-grade plywood spool with moisture-proof wrapping, reinforced corrugated carton |
| Delivery Time: | 7-15 working days after order confirmation |
| Payment Terms: | T/T,L/C,Western Union,PayPal |
| Supply Ability: | 50000 Meters per Month |
|
Detail Information |
|||
| Rated Current Output: | <= 50 MA/m (cementitious Overlay) | Coating Thickness: | 8-12 Um |
|---|---|---|---|
| Standard Coil Length: | 50 M, 100 M, 150 M, 300 M | Coil Weight 100m: | Approx. 2.9 Kg |
| Maximum Operating Voltage: | 12 V DC | Ribbon Dimensions: | 6.35 Mm (W) X 0.635 Mm (T) |
| Highlight: | MMO Ti Ribbon Anode 6.35mm,Concrete Structure Flexible ICCP,Mixed Metal Oxide Ribbon CP Anode |
||
Product Description
This Mixed Metal Oxide (MMO) coated titanium ribbon flexible anode is engineered for impressed current cathodic protection (ICCP) systems in reinforced concrete structures including bridge decks, parking garages, marine piers, concrete columns, and beams affected by chloride-induced corrosion. Manufactured with premium Grade 1 titanium substrate and precision-applied iridium-tantalum mixed metal oxide coating, it delivers exceptional electrochemical performance, long service life, and uniform current distribution across the entire protected structure.
- Flat ribbon profile (6.35mm x 0.635mm) maximizes surface contact area with concrete overlay for efficient current transfer
- MMO catalytic coating optimized for alkaline concrete environment with excellent pH resistance up to 13
- Uniform current distribution along entire ribbon length prevents localized under-protection or over-protection zones
- Compatible with cementitious grout, conductive coating, and thermal spray zinc anode encapsulation systems
- Meets NACE SP0290 and NACE SP0408 standards for impressed current cathodic protection of reinforced concrete
| Parameter | Specification |
|---|---|
| Model | MMO-R-6.35-CON |
| Anode Type | MMO/Ti Ribbon Flexible Anode |
| Substrate Material | Grade 1 Titanium per ASTM B265 |
| Coating Type | Iridium-Tantalum Mixed Metal Oxide |
| Ribbon Dimensions | 6.35 mm (W) x 0.635 mm (T) |
| Standard Coil Length | 50 m, 100 m, 150 m, 300 m |
| Rated Current Output | <= 50 mA/m (cementitious overlay) |
| Maximum Operating Voltage | 12 V DC |
| Design Life | >= 25 years |
| pH Resistance | Up to pH 13 |
| Coating Thickness | 8-12 um |
| Coil Weight 100m | Approx. 2.9 kg |
- Ideal for impressed current cathodic protection of reinforced concrete structures including bridge decks, parking garages, marine piers, concrete columns, and beams affected by chloride-induced corrosion
- The flexible form factor allows easy installation around complex geometries, ensuring complete coverage and uniform protection
- Suitable for both new construction and retrofit projects in cathodic protection systems conforming to NACE SP0169 and ISO 15589-1 standards
Supplied on durable export-grade spools with protective wrapping. Standard coil lengths available from 50 to 500 meters per spool. Custom lengths and configurations available upon request. Each shipment includes full quality documentation including coating inspection reports and mill test certificates.
