MMO Coated Titanium Wire Flexible Impressed Current Anode 1.0mm Dia Marine Grade with 15 Years Design Life for Marine CP
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | HIGH BROAD |
| Certification: | ISO 9001:2015, ISO 14001:2015 |
| Model Number: | MMO-W-1.0-MAR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Meters |
|---|---|
| Price: | USD 20.0-50.00 / Meter |
| Packaging Details: | Export-grade plywood spool with moisture-proof wrapping, reinforced corrugated carton |
| Delivery Time: | 7-15 working days after order confirmation |
| Payment Terms: | T/T,L/C,Western Union,PayPal |
| Supply Ability: | 50000 Meters per Month |
|
Detail Information |
|||
| Coating Type: | Iridium-Tantalum Mixed Metal Oxide Marine Grade | Design Life: | >= 15 Years (seawater) |
|---|---|---|---|
| Maximum Operating Voltage: | 12 V DC | Rated Current Output: | <= 500 MA/m (seawater) |
| Coating Thickness: | 8-12 Um | Wire Diameter: | 1.0 Mm +/- 0.05 Mm |
| Highlight: | MMO Ti Marine Wire Anode 1.0mm,Seawater Cathodic Protection Flexible,Mixed Metal Oxide ICCP Marine Anode |
||
Product Description
This Mixed Metal Oxide (MMO) coated titanium wire flexible anode is engineered for impressed current cathodic protection (ICCP) systems in marine and seawater cathodic protection applications including offshore platforms, ship hulls, jetty piles, sheet piling, dock structures, and seawater intake systems. Manufactured with premium Grade 1 titanium substrate and precision-applied iridium-tantalum mixed metal oxide coating, it delivers exceptional electrochemical performance, long service life, and uniform current distribution across the entire protected structure.
- Ultra-fine 1.0mm diameter ideal for precision cathodic protection in seawater and brackish water environments
- Excellent chlorine evolution resistance with specialized Ir-Ta coating formulation for marine applications
- Lightweight and highly flexible for installation on complex offshore structure geometries and tight spaces
- Low consumption rate in seawater electrolyte ensures extended service intervals and reduced maintenance
- Compatible with both galvanic and impressed current cathodic protection system configurations in marine settings
| Parameter | Specification |
|---|---|
| Model | MMO-W-1.0-MAR |
| Anode Type | MMO/Ti Wire Flexible Anode |
| Substrate Material | Grade 1 Titanium per ASTM B348 |
| Coating Type | Iridium-Tantalum Mixed Metal Oxide Marine Grade |
| Wire Diameter | 1.0 mm +/- 0.05 mm |
| Standard Coil Length | 100 m, 200 m, 300 m, 500 m |
| Rated Current Output | <= 500 mA/m (seawater) |
| Maximum Operating Voltage | 12 V DC |
| Design Life | >= 15 years (seawater) |
| Chlorine Evolution Resistance | Verified per NACE TM0294 |
| Coating Thickness | 8-12 um |
| Application Depth | Surface to 50 m |
Ideal for marine and seawater cathodic protection applications including offshore platforms, ship hulls, jetty piles, sheet piling, dock structures, and seawater intake systems. The flexible form factor allows easy installation around complex geometries, ensuring complete coverage and uniform protection. Suitable for both new construction and retrofit projects in cathodic protection systems conforming to NACE SP0169 and ISO 15589-1 standards.
Supplied on durable export-grade spools with protective wrapping. Standard coil lengths available from 50 to 500 meters per spool. Custom lengths and configurations available upon request. Each shipment includes full quality documentation including coating inspection reports and mill test certificates.
