MMO Coated Titanium Wire Flexible Anode 3.0mm Diameter Offshore Grade for 20 Years Design Life Subsea Cathodic Protection
Product Details:
| Place of Origin: | Shaanxi, China |
| Brand Name: | YLK |
| Certification: | ISO 9001:2015, ISO 14001:2015 |
| Model Number: | MMO-W-3.0-OP |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Meters |
|---|---|
| Price: | USD 3.50-12.00 / Meter |
| Packaging Details: | Export-grade plywood spool with moisture-proof wrapping, reinforced corrugated carton |
| Delivery Time: | 7-15 working days after order confirmation |
| Payment Terms: | T/T,L/C,Western Union,PayPal |
| Supply Ability: | 50000 Meters per Month |
|
Detail Information |
|||
| Rated Current Output: | <= 600 MA/m (seawater) | Coating Thickness: | 10-15 Um |
|---|---|---|---|
| Standard Coil Length: | 100 M, 200 M, 300 M, 500 M | Maximum Operating Voltage: | 24 V DC |
| Wire Diameter: | 3.0 Mm +/- 0.05 Mm | Maximum Water Depth: | Up To 500 M |
| Highlight: | MMO Ti Wire Offshore Anode 3.0mm,Subsea Platform Flexible ICCP Wire,Mixed Metal Oxide Offshore CP Anode |
||
Product Description
This Mixed Metal Oxide (MMO) coated titanium wire flexible anode is engineered for impressed current cathodic protection (ICCP) systems in subsea impressed current cathodic protection of offshore oil and gas platforms, subsea templates, flowline end terminations, riser bases, and deepwater production facilities. Manufactured with premium Grade 1 titanium substrate and precision-applied iridium-tantalum mixed metal oxide coating, it delivers exceptional electrochemical performance, long service life, and uniform current distribution across the entire protected structure.
- High-strength 3.0mm diameter wire with Grade 2 titanium option available for demanding deepwater and high-current offshore applications
- Superior resistance to hydrogen embrittlement and stress corrosion cracking in subsea environments
- Continuous wire length minimizes subsea splice connections reducing potential failure points in critical offshore CP systems
- Compatible with offshore platform ICCP power supply units and remote monitoring telemetry systems
- Performance validated against DNVGL-ST-F101 and NACE SP0176 standards for offshore corrosion control
| Parameter | Specification |
|---|---|
| Model | MMO-W-3.0-OP |
| Anode Type | MMO/Ti Wire Flexible Anode |
| Substrate Material | Grade 1 or Grade 2 Titanium per ASTM B348 |
| Coating Type | Iridium-Tantalum Mixed Metal Oxide Offshore Grade |
| Wire Diameter | 3.0 mm +/- 0.05 mm |
| Standard Coil Length | 100 m, 200 m, 300 m, 500 m |
| Rated Current Output | <= 600 mA/m (seawater) |
| Maximum Operating Voltage | 24 V DC |
| Design Life | >= 20 years (offshore) |
| Maximum Water Depth | Up to 500 m |
| Coating Thickness | 10-15 um |
| Hydrogen Embrittlement Resistance | NACE TM0198 compliant |
- Subsea impressed current cathodic protection of offshore oil and gas platforms
- Subsea templates, flowline end terminations, and riser bases
- Deepwater production facilities
- Flexible form factor allows easy installation around complex geometries
- Suitable for both new construction and retrofit projects conforming to NACE SP0169 and ISO 15589-1 standards
Supplied on durable export-grade spools with protective wrapping. Standard coil lengths available from 50 to 500 meters per spool. Custom lengths and configurations available upon request. Each shipment includes full quality documentation including coating inspection reports and mill test certificates.
