MMO Coated Titanium Mesh Flexible Anode with Iridium-Tantalum Coating for 25+ Years Design Life in 150mm x 50m Roll
Product Details:
| Place of Origin: | Shaanxi, China |
| Brand Name: | YLK |
| Certification: | ISO 9001:2015, ISO 14001:2015 |
| Model Number: | MMO-M-ROLL-RC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Meters |
|---|---|
| Price: | USD 3.50-12.00 / Meter |
| Packaging Details: | Export-grade plywood spool with moisture-proof wrapping, reinforced corrugated carton |
| Delivery Time: | 7-15 working days after order confirmation |
| Payment Terms: | T/T,L/C,Western Union,PayPal |
| Supply Ability: | 50000 Meters per Month |
|
Detail Information |
|||
| Coating Type: | Iridium-Tantalum Mixed Metal Oxide | Design Life: | >= 25 Years |
|---|---|---|---|
| Maximum Operating Voltage: | 12 V DC | Strand Width X Thickness: | 1.0 Mm X 0.5 Mm |
| Rated Current Output: | <= 15 MA/m (mortar Overlay) | Open Area Ratio: | > 55% |
| Highlight: | MMO Ti Mesh Roll Anode,Concrete Column Beam Flexible CP,Mixed Metal Oxide Roll Mesh Anode |
||
Product Description
This Mixed Metal Oxide (MMO) coated titanium mesh flexible anode is engineered for impressed current cathodic protection (ICCP) systems in reinforced concrete columns, beams, pile caps, abutment walls, retaining walls, and structural frame elements in buildings, bridges, and parking structures. Manufactured with premium Grade 1 titanium substrate and precision-applied iridium-tantalum mixed metal oxide coating, it delivers exceptional electrochemical performance, long service life, and uniform current distribution across the entire protected structure.
- Continuous roll format up to 50m long for efficient coverage of long structural elements without intermediate splices
- Lightweight expanded titanium mesh easily conforms to curved column surfaces and irregular beam profiles
- Self-adhesive backing option available for rapid installation on vertical and overhead concrete surfaces
- Compatible with sprayed concrete shotcrete and hand-applied cementitious mortar encapsulation methods
- Meets NACE SP0408 and European Standard EN 12696 requirements for cathodic protection of steel in concrete
| Parameter | Specification |
|---|---|
| Model | MMO-M-ROLL-RC |
| Anode Type | MMO/Ti Mesh Flexible Anode |
| Substrate Material | Grade 1 Titanium per ASTM B265 |
| Coating Type | Iridium-Tantalum Mixed Metal Oxide |
| Mesh Type | Expanded titanium diamond aperture |
| Roll Width x Length | 150 mm x 50 m (standard) |
| Rated Current Output | <= 15 mA/m (mortar overlay) |
| Maximum Operating Voltage | 12 V DC |
| Design Life | >= 25 years |
| Strand Width x Thickness | 1.0 mm x 0.5 mm |
| Open Area Ratio | > 55% |
| Adhesive Backing | Optional |
Ideal for impressed current cathodic protection of reinforced concrete columns, beams, pile caps, abutment walls, retaining walls, and structural frame elements in buildings, bridges, and parking structures. The flexible form factor allows easy installation around complex geometries, ensuring complete coverage and uniform protection.
Supplied on durable export-grade spools with protective wrapping. Standard coil lengths available from 50 to 500 meters per spool. Custom lengths and configurations available upon request. Each shipment includes full quality documentation including coating inspection reports and mill test certificates.
