MMO Coated Titanium Wire Anode with 4.0mm Diameter and Iridium-Tantalum Mixed Metal Oxide Coating for 25+ Years Design Life in Industrial Groundbed CP
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | HB |
| Certification: | ISO 9001:2015, ISO 14001:2015 |
| Model Number: | MMO-W-4.0-IND |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 Meters |
|---|---|
| Price: | USD 20.00-50.00 / Meter |
| Packaging Details: | Export-grade plywood spool with moisture-proof wrapping, reinforced corrugated carton |
| Delivery Time: | 7-15 working days after order confirmation |
| Payment Terms: | T/T,L/C,Western Union,PayPal |
| Supply Ability: | 50000 Meters per Month |
|
Detail Information |
|||
| Coating Type: | Iridium-Tantalum Mixed Metal Oxide Industrial Grade | Design Life: | >= 25 Years |
|---|---|---|---|
| Maximum Operating Voltage: | 50 V DC | Rated Current Output: | <= 500 MA/m (carbon Backfill) |
| Coating Thickness: | 10-15 Um | Wire Diameter: | 4.0 Mm +/- 0.05 Mm |
| Highlight: | MMO Ti Wire Industrial Anode 4.0mm,Heavy Industry Flexible ICCP Groundbed,Mixed Metal Oxide Industrial CP Anode |
||
Product Description
MMO Coated Titanium Wire Flexible Impressed Current Anode 4.0mm Dia for Heavy Industrial Facility Groundbed CP
This Mixed Metal Oxide (MMO) coated titanium wire flexible anode is engineered for impressed current cathodic protection (ICCP) systems in heavy industrial groundbed applications. Manufactured with premium Grade 1 titanium substrate and precision-applied iridium-tantalum mixed metal oxide coating, it delivers exceptional electrochemical performance, long service life, and uniform current distribution across protected structures.
Key Features
- Maximum 4.0mm wire diameter delivers highest current output capacity up to 500 mA/m for demanding industrial CP applications
- Heavy-duty Grade 2 titanium substrate option available for enhanced mechanical durability in industrial environments
- Ideal for protecting extensive plant piping networks, buried vessel bottoms, and tank farm underground infrastructure
- Pre-packaged in factory-assembled coke breeze anode segments for rapid field deployment in shallow horizontal groundbeds
- Designed for continuous operation under high-current industrial ICCP systems with 50V+ transformer-rectifier units
Technical Specifications
| Model | MMO-W-4.0-IND |
|---|---|
| Anode Type | MMO/Ti Wire Flexible Anode |
| Substrate Material | Grade 1 or Grade 2 Titanium per ASTM B348 |
| Coating Type | Iridium-Tantalum Mixed Metal Oxide Industrial Grade |
| Wire Diameter | 4.0 mm +/- 0.05 mm |
| Standard Coil Length | 100 m, 200 m, 300 m, 500 m |
| Rated Current Output | <= 500 mA/m (carbon backfill) |
| Maximum Operating Voltage | 50 V DC |
| Design Life | >= 25 years |
| Groundbed Type | Shallow horizontal, deep vertical |
| Coating Thickness | 10-15 um |
| Tensile Strength | >= 345 MPa (Grade 2) |
Applications
Ideal for heavy industrial impressed current cathodic protection groundbed systems in refineries, petrochemical plants, power generation facilities, LNG terminals, steel mills, and chemical processing complexes. The flexible form factor allows easy installation around complex geometries, ensuring complete coverage and uniform protection. Suitable for both new construction and retrofit projects in cathodic protection systems conforming to NACE SP0169 and ISO 15589-1 standards.
Packaging and Delivery
Supplied on durable export-grade spools with protective wrapping. Standard coil lengths available from 50 to 500 meters per spool. Custom lengths and configurations available upon request. Each shipment includes full quality documentation including coating inspection reports and mill test certificates.
