Propeller Shaft Aluminum Sacrificial Anode Collar Type 50mm Split Design 3kg Marine Grade Al-Zn-In Alloy
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | HB |
| Certification: | ISO 9001:2015, DNV-GL |
| Model Number: | HB-AH-008 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50 kg |
|---|---|
| Price: | USD 10-50 / kg |
| Packaging Details: | HB branded plywood case or pallet packaging with waterproof wrapping, export-grade fumigation-free certification |
| Delivery Time: | 7-15 working days after order confirmation |
| Payment Terms: | T/T, L/C, Western Union, PayPal |
| Supply Ability: | 50000 kg per Month |
|
Detail Information |
|||
| Alloy Type: | Al-Zn-In | Type: | Split Collar / Clamp-On |
|---|---|---|---|
| Shaft Diameter: | 50mm | Net Weight: | 3 Kg |
| Bolt Material: | Stainless Steel 316 | Electrochemical Capacity: | ≥2600 Ah/kg |
| Closed Circuit Potential: | -1.05 To -1.12V Vs Ag/AgCl | Application: | Propeller Shaft / Rudder Protection |
| Highlight: | Aluminum anode collar 50mm split design,Marine grade Al-Zn-In alloy anode,Propeller shaft sacrificial anode 3kg |
||
Product Description
HB-AH-008 - Propeller Shaft / Rudder Protection
The HB-AH-008 is a high-performance aluminum sacrificial anode manufactured by HB from Hunan, China. Engineered with Al-Zn-In alloy composition, this anode delivers superior cathodic protection for propeller shaft / rudder protection. Each anode undergoes rigorous quality control and electrochemical performance testing before shipment.
🔧 Product Features
- ✓ Al-Zn-In Alloy Composition – Optimized electrochemical properties provide ≥2600 Ah/kg capacity with -1.05 to -1.12V vs Ag/AgCl closed circuit potential
- ✓ High Current Efficiency – Delivers ≥90% current efficiency ensuring long-lasting cathodic protection
- ✓ Precision Casting – Manufactured using advanced gravity casting with homogeneous alloy distribution and minimal porosity
- ✓ Secure Insert Design – Galvanized steel core insert ensures reliable electrical continuity and mechanical integrity during service life
- ✓ Certified Quality – ISO 9001:2015 certified with DNV-GL type approval available; full traceability with batch number and test reports
📊 Technical Specifications
| Alloy Type | Al-Zn-In |
| Type | Split Collar / Clamp-On |
| Shaft Diameter | 50mm |
| Net Weight | 3 kg |
| Bolt Material | Stainless Steel 316 |
| Electrochemical Capacity | ≥2600 Ah/kg |
| Closed Circuit Potential | -1.05 to -1.12V vs Ag/AgCl |
| Application | Propeller Shaft / Rudder Protection |
🏭 Manufacturing Excellence
HB operates a state-of-the-art foundry in Hunan, China, specializing in sacrificial anode production since 2005. Our facility features:
- ● 5,000 square meter production workshop with automated casting lines
- ● In-house spectrometer for alloy composition verification on every batch
- ● Electrochemical testing laboratory per NACE and DNV standards
- ● Monthly production capacity of 50,000 kg across all anode types
📦 Packaging & Shipping
- Packaging: HB branded plywood case or fumigation-free pallet with waterproof wrapping
- MOQ: 50 kg (negotiable for trial orders)
- Delivery: 7-15 working days after order confirmation
- Payment: T/T, L/C, Western Union, PayPal accepted
- Inspection: Third-party inspection (SGS, BV, TUV) available upon request
